Hioki PQ3100 User Manual

153
14
Specications
14.1 General Specications
Operating environment Indoor use, pollution degree 2, altitude up to 3000 m (9843 ft.)
At an altitude of above 2000 m (6562 ft.), the measurement categories are lowered to
1000 V CAT II, 600 V CAT III.
Operating temperature
and humidity
Temperature: −20°C to 50°C (−4°F to 122°F)
When communicating via LAN or USB: 0°C to 50°C (32°F to 122°F)
When using the external control terminal: 0°C to 50°C (32°F to 122°F)
When running on battery: 0°C to 50°C (32°F to 122°F)
When charging battery: 10°C to 35°C (50°F to 95°F)
Humidity: 80% RH or less (no condensation)
Storage temperature
and humidity
−30°C to 60°C (−22°F to 140°F), 80% RH or less (no condensation)
When the instrument is not in use for an extended period, remove the battery pack
from the body and store in an environment of −20°C to 30°C (−4°F to 86°F).
Dust-proofness,
Water-proofness
IP30 (EN 60529)
Applicable standards Safety EN 61010
EMC EN 61326 Class A
Compliance standards Harmonics IEC 61000-4-7:2002 + A1:2008, IEC 61000-2-4 Class 3
Power quality IEC 61000-4-30:2015 Class S, EN 50160, IEEE 1159
Power supply • Z1002 AC Adapter
Rated supply voltage: 100 V to 240 V AC (Voltage uctuations of ±10% for the rated
supply voltage are taken into account.)
Rated supply frequency: 50 Hz/60 Hz
Anticipated transient overvoltage: 2500 V
Maximum rated power: 80 VA (including AC adapter), 35 VA (main unit only)
• Z1003 Battery Pack (Ni-MH 4500 mAh)
Rated supply voltage: 7.2 V DC
Recharge function Charges the battery regardless of whether the instrument is on or off.
Charging time 5 hours 30 min at a maximum (at 23°C, as a referential)
Continuous operating
time
When Z1003 Battery Pack is used (at 23°C, as a referential)
Approx. 8 hours (fully charged, continuous operation, with LCD backlight turned off
automatically and sensors not involving AC/DC sensors used)
Backup battery Approx. 10 years (at 23°C, as a referential)
For backup clock and setting conditions (Lithium battery)
Maximum recording
period
1 year (366 days)
Maximum recording
events
9999 events
Clock function Auto-calendar, leap-year correcting, 24-hour clock
Real-time clock
accuracy
±0.5 s per day (when main unit is on, within operating temperature and humidity range)
Display refresh rate Approx. 0.5 s
Display 6.5-inch TFT color LCD (640 × 480 dots)
Interface SD memory card, USB, LAN, RS-232C, external I/O
Dimensions Approx. 300W × 211H × 68D mm (11.81″W × 8.31″H × 2.68″D) (excluding protrusions)
Body Strap can be attached.
Mass Approx. 2.5 kg (88.2 oz.) (with Z1003 Battery Pack installed)
Product warranty period 3 years
14 Specications
14
Specications
