Screen Conguration
SET UP screen
A screen used to congure settings.
Display/switch screen: [SET UP] key
See “5 Setting Change (SET UP Screen)” (p. 63).
Measurement settings 1 screen
This screen is used to congure the wiring.
Measurement settings 2 screen
This screen is used to congure settings for calculation
method, energy cost, and icker (available after the
rmware update).
Recording settings screen
This screen is used to congure the settings for
recording.
Event settings 1 screen
This screen is used to congure the event threshold
value and hysteresis for voltage and current.
Event settings 2 screen
This screen is used to congure the timer event, external
event, and event waveform recording time.
System settings screen
This screen is used to congure the clock, beep sound,
language, display color, and phase name.
Interface settings screen
This screen is used to congure the settings for LAN,
RS-232C, and external output.
