Range Conguration and Combination Accuracy
3. While using the Model CT7126 AC Current Sensor
Power range conguration
Wiring
Current range
500.00 mA 5.0000 A 50.000 A
1P2W 500.00 W 5.0000 kW 50.000 kW
1P3W
1P3W1U
3P3W2M
3P3W3M
1.0000 kW 10.000 kW 100.00 kW
3P4W
3P4W2.5E
1.5000 kW 15.000 kW 150.00 kW
Display format varies according to the declared voltage settings.
Combination Accuracy
Current range 45 ≤ f ≤ 66 (Hz)
50.000 A 0.4% rdg.+0.112% f.s.
5.0000 A 0.4% rdg.+0.22% f.s.
500.0 mA 0.4% rdg.+1.3% f.s.
4. While using Model CT7731 AC/DC Auto-Zero Current Sensor
Power range conguration
Wiring
Current range
10.000 A 100.00 A
1P2W 10.000 kW 100.00 kW
1P3W
1P3W1U
3P3W2M
3P3W3M
20.000 kW 200.00 kW
3P4W
3P4W2.5E
30.000 kW 300.00 kW
Display format varies according to the declared voltage settings.
Combination Accuracy
Current range DC 45 ≤ f ≤ 66 (Hz)
100.00 A 1.5% rdg.+1.0% f.s. 1.1% rdg.+0.6% f.s.
10.000 A 1.5% rdg.+5.5% f.s. 1.1% rdg.+5.1% f.s.
