Hioki PQ3100 User Manual

191
Range Conguration and Combination Accuracy
7. While using the Model CT7044, CT7045, CT7046 AC Flexible Current Sensor
Power range conguration
Wiring
Current range Sensor range within ( )
50.000 A (600A) 500.00 A (600A) 5000.0 A (6000A)
1P2W 50.000 kW 500.00 kW 5.0000 MW
1P3W
1P3W1U
3P3W2M
3P3W3M
100.00 kW 1.0000 MW 10.000 MW
3P4W
3P4W2.5E
150.00 kW 1.5000 MW 15.000 MW
Display format varies according to the declared voltage settings.
Combination Accuracy
Current range 45 ≤ f ≤ 66 (Hz)
5000.0 A 1.6% rdg.+0.4% f.s.
500.00 A
50.000 A 1.6% rdg.+3.1% f.s.
8. While using the Model CT7116 AC Leakage Current Sensor
Power range conguration
Wiring
Current range
50.000 mA 500.00 mA 5.0000 A
1P2W 50.000 W 500.00 W 5.0000 kW
1P3W
1P3W1U
3P3W2M
3P3W3M
100.00 W 1.0000 kW 10.000 kW
3P4W
3P4W2.5E
150.00 W 1.5000 kW 15.000 kW
Display format varies according to the declared voltage settings.
Combination Accuracy
Current range 45 ≤ f ≤ 66 (Hz)
5.0000 A 1.1% rdg.+0.16% f.s.
500.00 mA 1.1% rdg.+0.7% f.s.
50.000 mA 1.1% rdg.+6.1% f.s.
14
Specications
