Hold Function
Operation in the hold state
• Hold operation also applies to the following measured values:
(1) Measured values to be stored onto the USB ash drive
(2) Measured values to be acquired using communications
(3) Measured values to be outputted as an analog signal
• Waveforms, the clock, and the peak-over display are refreshed.
• When the PEAK HOLD key is pressed, data is replaced with the latest internal data.
• The instrument retains the data without updating it even if the interval time set in the time control
function has elapsed.
• Average and integration calculations continue to be performed internally.
• Settings that a󰀨ect measured values, such as range and the LPF settings, cannot be changed.
• When the range setting is set to AUTO, the range is xed to that at the time when the HOLD key
was pressed.
• The hold function cannot be used together with the peak hold function.
• Waveforms shown on the screen and D/A output waveforms are not a󰀨ected by the hold
operation.
• The data frozen during hold operation is not displayed when the HOLD key was pressed, but
rather the data is retained internally when the HOLD key was pressed among those acquired at
data refresh intervals.
HIOKI PW8001A961-00
