110
Peak Hold Function
Operation in the peak hold state
Peak hold operation also applies to the following measured values:
(1) Measured values to be stored onto the USB ash drive
(2) Measured values to be acquired using communications
(3) Measured values to be outputted as an analog signal
Waveforms, the clock, and the peak-over display are refreshed.
When the display is overloaded, it will show [------]. In this case, cancel the peak hold operation,
then switch the present range over to a range in which the overload condition will not occur.
The maximum value is determined using the absolute value of measured values. (However, this
method does not a󰀨ect voltage or current peak values.)
For example, if a power of −60 W is inputted after that of 50 W was inputted, the display will
indicate [−60 W] because the absolute value of −60 W is greater than that of 50 W.
When the HOLD key is pressed, the peak hold value is reset, and another peak hold operation
starts from that point.
The instrument retains the peak-hold value without updating it even if the interval time set in the
time control function has elapsed.
During average calculation, peak hold operation applies to measured values after averaging.
Settings that a󰀨ect measured values such as range and the LPF settings cannot be changed.
When the range setting is set to [AUTO], the range is xed to that at the time when the
PEAK HOLD key was pressed.
The hold function cannot be used together with the peak hold function.
Waveforms shown on the screen and D/A output waveforms are not a󰀨ected by the peak hold
operation.
The time when the maximum value occurred is not displayed.
The peak hold function does not a󰀨ect to integrated values.
HIOKI PW8001A961-00
