Measured Value Save Data Format
7.8 Measured Value Save Data Format
Header structure
The following header information (which consists of parameter names saved in the rst line of the
le) is used when measured data is automatically or manually saved in a le.
• The selected parameters are outputted beginning from top to bottom and from left to right of the
table.
• Measured data is outputted starting from the rst line immediately below the header in the header
order.
• The rst four parameters (Date, Time, Status, and Status 1 to Status 8) and the harmonic status
(HARM Status) are always outputted regardless of whether they have been selected.
• The instrument outputs the Status 1 to Status 8 information of installed input modules.
• If the motor analysis option is installed, the status (Status M) of the motor channel is outputted.
Output items
Instrument
symbol
Header and order
Year, month, day Date
Time Time
Time (ms)
Time (ms)
(Outputted only when the interval setting is less than 1 s)
Elapsed time Etime
Elapsed time (ms)
Etime (ms)
(Outputted only when the interval setting is less than 1 s)
Status Status
Channel status Status1, Status2, Status3, Status4, Status5, Status6, Status7, Status8
Motor status StatusM
Basic measurement items
(The string Slv is added to each header of the basic measurement items for the subordinate units when it is operating in numerical
synchronization mode.)
The basic measurement items for subordinate units are outputted after the basic measurement items for the master unit is
outputted.
Voltage RMS value Urms
Urms1, Urms2, Urms3, Urms4, Urms5, Urms6, Urms7, Urms8
Urms12, Urms23, Urms34, Urms45, Urms56, Urms67, Urms78
Urms123, Urms234, Urms345, Urms456, Urms567, Urms678
RMS equivalent of average
rectied voltage value
Umn
Umn1, Umn2, Umn3, Umn4, Umn5, Umn6, Umn7, Umn8
Umn12, Umn23, Umn34, Umn45, Umn56, Umn67, Umn78
Umn123, Umn234, Umn345, Umn456, Umn567, Umn678
Voltage AC component Uac Uac1, Uac2, Uac3, Uac4, Uac5, Uac6, Uac7, Uac8
Voltage simple average Udc Udc1, Udc2, Udc3, Udc4, Udc5, Udc6, Udc7, Udc8
Voltage fundamental wave
component
Ufnd Ufnd1, Ufnd2, Ufnd3, Ufnd4, Ufnd5, Ufnd6, Ufnd7, Ufnd8
Voltage waveform peak (+) Upk+ PUpk1, PUpk2, PUpk3, PUpk4, PUpk5, PUpk6, PUpk7, PUpk8
Voltage waveform peak (−) Upk− MUpk1, MUpk2, MUpk3, MUpk4, MUpk5, MUpk6, MUpk7, MUpk8
Total harmonic voltage
distortion
Uthd Uthd1, Uthd2, Uthd3, Uthd4, Uthd5, Uthd6, Uthd7, Uthd8
Voltage ripple factor Urf Urf1, Urf2, Urf3, Urf4, Urf5, Urf6, Urf7, Urf8
Voltage unbalance rate Uunb Uunb123, Uunb234, Uunb345, Uunb456, Uunb567, Uunb678
Saving Data and Managing Files
