Factory Default Settings
6.3 Factory Default Settings
The following tables list the instrument’s factory default settings.
The measurement screen and recorded data settings will also be reset.
Parameter Default setting
Current input Probe 1
Wiring 1P2W
Synchronization source U1, U2, U3, U4, U5, U6, U7,
U8 (depends the number of
installed modules)
U range 1500 V
U auto-ranging O
U rectier RMS
VT ratio 1.0 (o)
I range Sensor’s rated current
I auto-ranging O
I rectier RMS
CT ratio 1.0 (o)
LPF O
Sensor phase correction O
Integration mode RMS
Upper frequency limit U7001: 1 MHz
U7005: 2 MHz
Lower frequency limit 10 Hz
ZC HPF On
Delta conversion O
Data refresh interval 50 ms
Measurement mode Wideband
Grouping Type 1
THD calculation order 500th
THD calculation method THD-F
Averaging mode O
Power calculation method Type 1
Eciency calculation Pin,
Pout
P1
Display language* Japanese
Beep tone On
Startup screen selection Wiring (Wiring screen)
GP-IB address* 1
BNC-and-opt synchronization O
(Motor) synchronization
source
DC
Motor analysis option wiring
setting
Torque, Speed
Parameter Default setting
Torque input Analog
(Motor) LPF O
Motor voltage range 5 V
RPM input Pulse
Torque scaling 1.0
Pulse count 2
Number of motor poles 4
Slip input frequency fU1
Phase ADJ 0.000
Output range 1 V f.s.
Integration full scale 1
Output items D/A1 to D/A16: WAVE U1,
I1U2, I2, U3, I3, . . . , U8, I8
D/A17 to D/A20: Trend
Urms1
(depends on the number of
installed modules)
Data saving interval 1 s
Timer O
Timer setup 1 min.
Real time control O
Text saving format CSV*
Auto-save O
Manual save O
Screenshot O
Comment entry O
Simultaneous saving of
settings
O
DHCP* O
IP address* 192.168.1.1
Subnet mask* 255,255,255.0
Default gateway* 0.0.0.0
RS-232C connection* RS-232C
RS-232C communications
speed
115200 bps
Time zone GMT +09:00*
Date format yyyyMMdd*
Delimiter for date Hyphen (-)*
* Parameter not initialized by the system reset, but by the boot key reset. See “Boot key reset” (p. 117).
