Example Measurement Setups
Evaluating conversion eciency of inverters with built-in SiC
The instrument can measure the conversion-eciency of inverters using modern devices such as
SiC and GaN at high precision.
Three-phase
power supply
Load
Analyzing of motors used for vehicles including EV and HEV
The instrument automatically follows a frequency that uctuates from a frequency of at least 0.1 Hz,
allowing power to be measured in transient conditions, such as motor behavior during start and
acceleration.
Inverter
Motor
Load
Pulse
encoder
Torque
sensor
Battery
