140
Measured Value Save Data Format
Output items
Instrument
symbol
Header and order
500th
Harmonic voltage
RMS value
Uk HU1L500, HU2L500, HU3L500, HU4L500, HU5L500, HU6L500, HU7L500, HU8L500
Harmonic voltage
content percentage
HDUk
HU1D500, HU2D500, HU3D500, HU4D500, HU5D500, HU6D500, HU7D500,
HU8D500
Harmonic voltage
phase angle
θ
Uk
HU1P500, HU2P500, HU3P500, HU4P500, HU5P500, HU6P500, HU7P500,
HU8P500
Harmonic current
RMS value
Ik HI1L500, HI2L500, HI3L500, HI4L500, HI5L500, HI6L500, HI7L500, HI8L500
Harmonic current
content percentage
HDIk HI1D500, HI2D500, HI3D500, HI4D500, HI5D500, HI6D500, HI7D500, HI8D500
Harmonic current
phase angle
θ
Ik HI1P500, HI2P500, HI3P500, HI4P500, HI5P500, HI6P500, HI7P500, HI8P500
Harmonic active
power
Pk
HP1L500, HP2L500, HP3L500, HP4L500, HP5L500, HP6L500, HP7L500, HP8L500,
HP12L500, HP23L500, HP34L500, HP45L500, HP56L500, HP67L500, HP78L500,
HP123L500, HP234L500, HP345L500, HP456L500, HP567L500, HP678L500
Harmonic power
content percentage
HDPk
HP1D500, HP2D500, HP3D500, HP4D500, HP5D500, HP6D500, HP7D500,
HP8D500,
HP12D500, HP23D500, HP34D500, HP45D500, HP56D500, HP67D500, HP78D500,
HP123D500, HP234D500, HP345D500, HP456D500, HP567D500, HP678D500
Harmonic voltage-
vs.-current phase
dierence
θ
k
HP1P500, HP2P500, HP3P500, HP4P500, HP5P500, HP6P500, HP7P500,
HP8P500,
HP12P500, HP23P500, HP34P500, HP45P500, HP56P500, HP67P500, HP78P500,
HP123P500, HP234P500, HP345P500, HP456P500, HP567P500, HP678P500
Harmonic
synchronization
frequency
fHRM HF1, HF2, HF3, HF4, HF5, HF6, HF7, HF8
Status data
Status information is used to express measurement conditions at the time the measured data was
saved using a 32-bit hexadecimal values.
Status is the logical sum of Status 1 to Status 8 as well as Status M.
Example: If Bit 11 (ZU) of Status 2 is on and Bit 17 (ZM) of Status M is on, Bit 11 and Bit 17 of
Status will be set to on.
Status of each channel (Status 1 through Status 8)
Status 1 through Status 8 indicate the status of individual channels.
Example: Status 3 indicates the status of channel 3.
Each of the 32 bits is assigned to contain the following information:
Bit 31 Bit 30 Bit 29 Bit 28 Bit 27 Bit 26 Bit 25 Bit 24
– – – – – – – –
Bit 23 Bit 22 Bit 21 Bit 20 Bit 19 Bit 18 Bit 17 Bit 16
– – – – – – – –
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
– UCU ZP ZI ZU DP DI DU
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
– – – – RI RU PI PU
