Measured Value Save Data Format
Output items
Instrument
symbol
Header and order
Sum of integrated positive
and negative current values
Ih IH1, IH2, IH3, IH4, IH5, IH6, IH7, IH8
Integrated positive power
value
WP+
PWP1, PWP2, PWP3, PWP4, PWP5, PWP6, PWP7, PWP8
PWP12, PWP23, PWP34, PWP45, PWP56, PWP67, PWP78
PWP123, PWP234, PWP345, PWP456, PWP567, PWP678
Integrated negative power
value
WP−
MWP1, MWP2, MWP3, MWP4, MWP5, MWP6, MWP7, MWP8
MWP12, MWP23, MWP34, MWP45, MWP56, MWP67, MWP78
MWP123, MWP234, MWP345, MWP456, MWP567, MWP678
Sum of integrated positive
and negative power values
WP
WP1, WP2, WP3, WP4, WP5, WP6, WP7, WP8
WP12, WP23, WP34, WP45, WP56, WP67, WP78
WP123, WP234, WP345, WP456, WP567, WP678
E󰀩ciency η E󰀨1, E󰀨2, E󰀨3, E󰀨4
Loss value Loss LOSS1, LOSS2, LOSS3, LOSS4
Torque Tq Tq1, Tq2, Tq3, Tq4
RPM Spd Spd1, Spd2, Spd3, Spd4
Motor power Pm Pm1, Pm2, Pm3, Pm4
Slip Slip Slip1, Slip2, Slip3, Slip4
Free input during
independent input mode
operation
CH CHA, CHB, CHC, CHD, CHE, CHF, CHG, CHH
Harmonic measurement items
Status HRMStatus
0th
order
Harmonic voltage
RMS value
Uk HU1L000, HU2L000, HU3L000, HU4L000, HU5L000, HU6L000, HU7L000, HU8L000
Harmonic voltage
content percentage
HDUk
HU1D000, HU2D000, HU3D000, HU4D000, HU5D000, HU6D000, HU7D000,
HU8D000
Harmonic voltage
phase angle
θ
Uk
HU1P000, HU2P000, HU3P000, HU4P000, HU5P000, HU6P000, HU7P000,
HU8P000
Harmonic current
RMS value
Ik HI1L000, HI2L000, HI3L000, HI4L000, HI5L000, HI6L000, HI7L000, HI8L000
Harmonic current
content percentage
HDIk HI1D000, HI2D000, HI3D000, HI4D000, HI5D000, HI6D000, HI7D000, HI8D000
Harmonic current
phase angle
θ
Ik HI1P000, HI2P000, HI3P000, HI4P000, HI5P000, HI6P000, HI7P000, HI8P000
Harmonic active
power
Pk
HP1L000, HP2L000, HP3L000, HP4L000, HP5L000, HP6L000, HP7L000, HP8L000,
HP12L000, HP23L000, HP34L000, HP45L000, HP56L000, HP67L000, HP78L000,
HP123L000, HP234L000, HP345L000, HP456L000, HP567L000, HP678L000
Harmonic power
content percentage
HDPk
HP1D000, HP2D000, HP3D000, HP4D000, HP5D000, HP6D000, HP7D000,
HP8D000,
HP12D000, HP23D000, HP34D000, HP45D000, HP56D000, HP67D000, HP78D000
HP123D000, HP234D000, HP345D000, HP456D000, HP567D000, HP678D000
Harmonic voltage-
vs.-current phase
di󰀨erence
θ
k
HP1P000, HP2P000, HP3P000, HP4P000, HP5P000, HP6P000, HP7P000,
HP8P000,
HP12P000, HP23P000, HP34P000, HP45P000, HP56P000, HP67P000, HP78P000,
HP123P000, HP234P000, HP345P000, HP456P000, HP567P000, HP678P000
nth
order
(omitted) — The last three digits indicate the order n.
