Page #215 background image
209
Detailed Specications of Measurement Parameters
Power range conguration
(1) With a 20 A sensor
Voltage, wiring
conguration, current
400.000 mA 800.000 mA 2.00000 A 4.00000 A 8.00000 A 20.0000 A
6.00000 V
1P2W 2.40000 4.80000 12.0000 24.0000 48.0000 120.000
1P3W, 3V3A
3P3W (2M, 3M)
4.80000 9.60000 24.0000 48.0000 96.0000 240.000
3P4W 7.20000 14.4000 36.0000 72.0000 144.000 360.000
15.0000 V
1P2W 6.00000 12.0000 30.0000 60.0000 120.000 300.000
1P3W, 3V3A
3P3W (2M, 3M)
12.0000 24.0000 60.0000 120.000 240.000 600.000
3P4W 18.0000 36.0000 90.0000 180.000 360.000 900.000
30.0000 V
1P2W 12.0000 24.0000 60.0000 120.000 240.000 600.000
1P3W, 3V3A
3P3W (2M, 3M)
24.0000 48.0000 120.000 240.000 480.000 1.20000 k
3P4W 36.0000 72.0000 180.000 360.000 720.000 1.80000 k
60.0000 V
1P2W 24.0000 48.0000 120.000 240.000 480.000 1.20000 k
1P3W, 3V3A
3P3W (2M, 3M)
48.0000 96.0000 240.000 480.000 960.000 2.40000 k
3P4W 72.0000 144.000 360.000 720.000 1.44000 k 3.60000 k
150.000 V
1P2W 60.0000 120.000 300.000 600.000 1.20000 k 3.00000 k
1P3W, 3V3A
3P3W (2M, 3M)
120.000 240.000 600.000 1.20000 k 2.40000 k 6.00000 k
3P4W 180.000 360.000 900.000 1.80000 k 3.60000 k 9.00000 k
300.000 V
1P2W 120.000 240.000 600.000 1.20000 k 2.40000 k 6.00000 k
1P3W, 3V3A
3P3W (2M, 3M)
240.000 480.000 1.20000 k 2.40000 k 4.80000 k 12.0000 k
3P4W 360.000 720.000 1.80000 k 3.60000 k 7.20000 k 18.0000 k
600.000 V
1P2W 240.000 480.000 1.20000 k 2.40000 k 4.80000 k 12.0000 k
1P3W, 3V3A
3P3W (2M, 3M)
480.000 960.000 2.40000 k 4.80000 k 9.60000 k 24.0000 k
3P4W 720.000 1.44000 k 3.60000 k 7.20000 k 14.4000 k 36.0000 k
1.50000 kV
1P2W 600.000 1.20000 k 3.00000 k 6.00000 k 12.0000 k 30.0000 k
1P3W, 3V3A
3P3W (2M, 3M)
1.20000 k 2.40000 k 6.00000 k 12.0000 k 24.0000 k 60.0000 k
3P4W 1.80000 k 3.60000 k 9.00000 k 18.0000 k 36.0000 k 90.0000 k
The following units of measurement are used: for active power (P), watt (W); for apparent power (S), volt-ampere (VA);
and for reactive power (Q), volt-ampere reactive (var).
Multiply the gures given in this table by 1/10 if using a 2 A sensor, by 10 if using a 200 A sensor, or by 100 if using a
2 kA sensor.
Specications
HIOKI PW8001A961-00
