Hioki PW8001-01 User Manual

222
U7001 2.5MS/s Input Unit
Accuracy specications
Apparent power
(S) measurement
accuracy
(Voltage accuracy) + (current accuracy)
±
10 digits
Reactive power
(Q) measurement
accuracy
For any condition except if
φ
= 0
°
or
±
180
°
(Apparent power accuracy)
±
{1−sin[
φ
+ (Power phase angle accuracy)] / sin
φ
}
×
(100% of reading)
±
[
√
(1.001 −
λ
2
) −
√
(1 −
λ
2
)]
×
(100% of range)
For
φ
= 0
°
and
±
180
°
(Apparent power accuracy)
±
[sin(Power phase angle accuracy)]
×
(100% of range)
±
(3.16% of range)
The symbol
λ
designates the display value of the power factor.
Power factor (
λ
)
measurement
accuracy
For any condition except if
φ
=
±
90
°
±
{1 − cos[
φ
+ (Power phase angle accuracy)] / cos
φ
}
×
(100% of reading)
±
50 digits
For
φ
=
±
90
°
±
cos[
φ
+ (Di󰀨erence accuracy)]
×
(100% of range)
±
50 digits
The symbol
φ
designates the display value of the power phase angle.
Both of the above are specied when voltage or current of its range rating is inputted.
Waveform peak
measurement
accuracy
Voltage and current RMS value accuracy
±
1% of range
(300% of range is applied as a peak range)
E󰀨ects of temperature Add the following to the voltage, current, and active power accuracy within the range of
0
°
C to 20
°
C or 26
°
C to 40
°
C:
When Probe 1 is used
±
0.01% of reading per degree centigrade
Add another 0.01% of range per degree centigrade for DC.
When Probe 2 is used
Voltage:
±
0.01% of reading per degree centigrade
Add another 0.01% of range per degree centigrade for DC.
Current, active power:
±
0.03% of reading per degree centigrade
Add another 0.06% of range per degree centigrade for DC.
Common-mode voltage
rejection ratio
(E󰀨ects of common-
mode voltage)
When frequency is 50 Hz/60 Hz: 100 dB or more
When frequency is 100 kHz: 80 dB typical
Specied for CMRR when the maximum input voltage is applied between the voltage
input terminals and the enclosure for all measurement ranges.
E󰀨ects of external
magnetic elds
±
1% of range or less
(in a magnetic eld of 400 A/m, DC or 50 Hz/60 Hz)
E󰀨ects of the power
factor on the active
power
For any condition except if
φ
=
±
90
°
±
{1 − cos[
φ
+ (Phase accuracy)] / cos
φ
}
×
(100% of reading)
For
φ
=
±
90
°
±
cos[
φ
+ (Phase accuracy)]
×
(100% of VA)
