Hioki PW8001-01 User Manual

221
U7001 2.5MS/s Input Unit
(3) Specications common to current measurement
Input terminal prole Probe 1: Dedicated connector (ME15W)
Probe 2: Metallic BNC terminal (female)
Select either Probe 1 (current sensor input) or Probe 2 (external input) based on the
setting. The channels of the same wiring conguration have the same input setting.
Input method Current sensor input method
Range Probe 1:
40 mA, 80 mA, 200 mA, 400 mA, 800 mA, 2 A (with a 2 A sensor)
400 mA, 800 mA, 2 A, 4 A, 8 A, 20 A (with a 20 A sensor)
4 A, 8 A, 20 A, 40 A, 80 A, 200 A (with a 200 A sensor)
40 A, 80 A, 200 A, 400 A, 800 A, 2 kA (with a 2000 A sensor)
100 mA, 200 mA, 500 mA, 1 A, 2 A, 5 A (with a 5 A sensor)
1 A, 2 A, 5 A, 10 A, 20 A, 50 A (with a 50 A sensor)
10 A, 20 A, 50 A, 100 A, 200 A, 500 A (with a 500 A sensor)
100 A, 200 A, 500 A, 1 kA, 2 kA, 5 kA (with a 5000 A sensor)
20 A, 40 A, 100 A, 200 A, 400 A, 1 kA (with a 1000 A sensor)
Selectable for each wiring
(Only when the same sensors are used for all channels of the same wiring conguration)
Probe 2:
1 kA, 2 kA, 5 kA, 10 kA, 20 kA, 50 kA (0.1 mV/A)
100 A, 200 A, 500 A, 1 kA, 2 kA, 5 kA (1 mV/A)
10 A, 20 A, 50 A, 100 A, 200 A, 500 A (10 mV/A)
1 A, 2 A, 5 A, 10 A, 20 A, 50 A (100 mV/A)
100 mA, 200 mA, 500 mA, 1 A, 2 A, 5 A (1 V/A)
(0.1 V, 0.2 V, 0.5 V, 1.0 V, 2.0 V, 5.0 V range)
The input rate and range can be selected for each wiring.
The sensor input rate can be set.
Crest factor 3 relative to current range rating (however, 1.5 for 5 V range of Probe 2)
Input resistance,
input capacity
Probe 1: 1 M
Ω ±
50 k
Ω
Probe 2: 1 M
Ω ±
50 k
Ω
, 22 pF typical
Maximum input
voltage
Probe 1: 8 V,
±
12 V peak (10 ms or less)
Probe 2: 15 V,
±
20 V peak (10 ms or less)
Specications
HIOKI PW8001A961-00
