188
Specications of Input, Output, and Measurement
Specications of motor analysis (optional)
(1) Specications common to analog DC input, frequency input, and pulse input
Number of input
channels
8 channels
Channel Input parameter
Ch. A, Ch. C, Ch. E, Ch. G Analog DC, frequency, pulse
Ch. B, Ch. D, Ch. F, Ch. H Frequency, pulse
Operating mode Motor analysis mode
Measurement or detection item (input type)
Number of maximum
analysis parameters
Pattern 1 Torque (analog/frequency), speed (pulse) 4 motors
Pattern 2 Torque (analog/frequency), speed (pulse), direction,
Origin (pulse)
2 motors
Pattern 3 Torque (analog/frequency), speed (pulse) ,direction 2 motors
Pattern 4 Torque (analog/frequency), speed (pulse), origin (pulse) 2 motors
Pattern 5 Torque (analog/frequency), speed (analog) 2 motors
Individual input mode
Ch. A, Ch. C, Ch. E, Ch. G: DC voltage measurement, frequency measurement
Ch. B, Ch. D, Ch. F, Ch. H: Frequency measurement
Input terminal prole Isolated BNC connector
Input method Function-isolated input and single-end input
Between-channels function isolation
Input resistance (DC) 1 M
Ω
±
50 k
Ω
Maximum input
voltage
20 V
Maximum rated line-
to-ground voltage
50 V (50 Hz/60 Hz)
Measurement item Voltage, torque, RPM, frequency, slip, motor power
Synchronization
source
Same as those specied in the basic measurement specications (The e󰀨ective frequency
range and e󰀨ective input range are also the same.)
In motor analysis mode
Pattern 1: Two types, for Ch. A and Ch. B as well as Ch. C and Ch. D, can
be set in [A-D].
Two types, for Ch. E and F as well as Ch. G and Ch. H, can be
set in [E-H].
Pattern 2 to Pattern 5: One type can be set in each of [A-D] and [E-H].
In individual input mode
Two types, for Ch. A and Ch. B as well as Ch. C and Ch. D, can be set in [A-D].
Two types, for Ch. E and Ch. F as well as Ch. G and Ch. H, can be set in [E-H].
Lower measurement
frequency limit
Select from among the following frequency values for each motor synchronization source:
0.1 Hz, 1 Hz, 10 Hz, 100 Hz
Upper measurement
frequency limit
Select from among the following frequency values for each motor synchronization source:
100 Hz, 500 Hz, 1 kHz, 5 kHz, 10 kHz, 50 kHz, 100 kHz, 500 kHz, 1 MHz, 2 MHz
Input frequency
source
Select from among fU1 to fU8 or 1 to 8.
The frequency for slip calculation can be set.
Number of motor
poles
2 to 254
Z-phase pulse
detection reference
The reference for detecting Zph of the synchronization source can be set in operating
mode 2 or 4.
Rising edge, falling edge
HIOKI PW8001A961-00
