172
Controlling the Instrument with Communications Commands
Uploading les manually
Any les saved in the USB ash drive connected to the instrument can be sent to the FTP server of
the computer anytime.
Only les can be manually sent. No folders can be sent manually.
Operating procedure
1
Set and connect the LAN on the instrument.
See “9.1 Connecting and Setting the LAN Interface” (p. 158).
2
Set the FTP server on the receiving side (computer).
3
Congure the FTP client using the instrument.
See “9.4 Sending Data Using the FTP Client Function” (p. 168).
4
Send les to the FTP server on the [FILE] screen.
See “Manual le transfer (uploading to an FTP server)” (p. 136).
Display screen [FILE]
11
22
1
Tap the le to be sent.
2
Tap [FTP send] to open the setting
window.
44
33
3
Congure the FTP client.
See “Setting automatic le upload” (p. 168).
4
Tap [Send].
The le is transferred to the specied FTP
server.
9.5 Controlling the Instrument with
Communications Commands
The computer sends communications commands, which can control the instrument and
communicate with it.
Connect the instrument and computer using an RS-232C, GP-IB, or LAN cable.
For details about the communications commands, see the Communication Command Instruction
Manual.
HIOKI PW8001A961-00
