Waveform/Analog Output (Waveform and D/A Output Option)
Output rates
Analog output is generated as a voltage of
±
5 V DC for a value of the full scale.
At full scale, the voltage listed in the following table will be output.

: Has polarity
Selected output parameter Notation
Output
voltage
polarity
Rated output voltage
Voltage RMS value Urms 0 V to +5 V DC for a value of 0% to 100% of the range
RMS equivalent of
average rectied voltage
value
Umn 0 V to +5 V DC for a value of 0% to 100% of the range
Voltage AC component Uac 0 V to +5 V DC for a value of 0% to 100% of the range
Voltage simple average Udc

±
5 V DC for a value of
±
100% of the range
Voltage fundamental
wave component
Ufnd 0 V to +5 V DC for a value of 0% to 100% of the range
Voltage waveform peak
(+)
Upk+

±
5 V DC for a value of
±
300% of the range
Voltage waveform peak
(−)
Upk−

±
5 V DC for a value of
±
300% of the range
Total harmonic voltage
distortion
Uthd 0 V to +5 V DC for a value of 0% to 500%
Voltage ripple factor Urf 0 V to +5 V DC for a value of 0% to 500%
Voltage unbalance rate Uunb 0 V to +5 V DC for a value of 0% to 100%
Current RMS value Irms 0 V to +5 V DC for a value of 0% to 100% of the range
RMS equivalent of current
average rectied value
Imn 0 V to +5 V DC for a value of 0% to 100% of the range
Current AC component Iac 0 V to +5 V DC for a value of 0% to 100% of the range
Current simple average Idc

±
5 V DC for a value of
±
100% of the range
Current fundamental
wave component
Ifnd 0 V to +5 V DC for a value of 0% to 100% of the range
Current waveform peak
(+)
Ipk+

±
5 V DC for a value of
±
300% of the range
Current waveform peak
(−)
Ipk−

±
5 V DC for a value of
±
300% of the range
Total harmonic current
distortion
Ithd 0 V to +5 V DC for a value of 0% to 500%
Current ripple factor Irf 0 V to +5 V DC for a value of 0% to 500%
Current unbalance rate Iunb 0 V to +5 V DC for a value of 0% to 100%
Active power P

P1, P2, P3, P4, P5, P6, P7, P8:
(Voltage range)
×
(Current range)
P12, P23, P34, P45, P56, P67, P78:
[(Voltage range)
×
(Current range)]
×
2
P123, P234, P345, P456, P567, P678 (3V3A, 3P3W3M):
[(Voltage range)
×
(Current range)]
×
2
P123, P234, P345, P456, P567, P678 (3P4W):
[(Voltage range)
×
(Current range)]
×
3
Example: For 3P4W, P123, 300 V range, 10 A range
300 V
×
10 A
×
3 = 9 kW
(Thus, the full scale is calculated.)
±
5 V DC for a value of
±
9 kW f.s.
Fundamental wave active
power
Pfnd

Same as active power (P)
