Waveform/Analog Output (Waveform and D/A Output Option)
Selected output parameter Notation
Output
voltage
polarity
Rated output voltage
Apparent power S S1, S2, S3, S4, S5, S6, S7, S8:
(Voltage range)
×
(Current range)
S12, S23, S34, S45, P56, S67, S78:
[(Voltage range)
×
(Current range)]
×
2
S123, S234, S345, S456, S567, S678 (3V3A, 3P3W3M):
[(Voltage range)
×
(Current range)]
×
2
S123, S234, S345, S456, S567, S678 (3P4W):
[(Voltage range)
×
(Current range)]
×
3
Example: For S34, 150 V range, 10 A range
150 V
×
10 A
×
2 = 3 kW
(Thus, the full scale is calculated.)
0 V to +5 V DC for a value of 0 to 3 kW f.s.
Fundamental wave
apparent power
Sfnd Same as apparent power (S)
Reactive power Q

Same as active power (P)
Fundamental wave
reactive power
Qfnd

Same as active power (P)
Power factor
λ

±
5 V DC for a power factor of
±
1
Fundamental wave power
factor
λ
fnd

±
5 V DC for a fundamental wave power factor of
±
1
Voltage phase angle
θ
U

±
5 V DC for a voltage phase angle of
±
180
°
Current phase angle
θ
I

Same as voltage phase angle (
θ
U)
Power phase angle
φ

Same as voltage phase angle (
θ
U)
Voltage frequency,
current frequency
fU, fI +5 V DC for the upper frequency limit setting
Integrated positive
current value
Ih+ Same as sum of positive and negative current values (Ih)
Integrated negative
current value
Ih− *
2
Same as sum of positive and negative current values (Ih)
Sum of positive and
negative current values
Ih

(Current range)
×
(Integration full scale)
Example: If integrating for 1 h with the 10 A range
The current integration full scale is determined to be 10 Ah.*
1
±
5 V DC for a value of
±
10 Ah
Integrated positive power
value
WP+ Same as total positive- and negative- direction power
integrated value (WP)
Integrated negative power
value
WP- *
2
Same as sum of positive and negative power values (WP)
Sum of integrated
positive and negative
power values
WP

WP1, WP2, WP3, WP4, WP5, WP6, WP7, WP8:
(Voltage range)
×
(Current range)
×
(Integration full
scale)
WP12, WP23, WP34, WP45, WP56, WP67, WP78:
[(Voltage range)
×
(Current range)
×
(Integration full
scale)]
×
2
WP123, WP234, WP345, WP456, WP567, WP678 of 3V3A,
3P3W3M:
[(Voltage range)
×
(Current range)
×
(Integration full
scale)]
×
2
WP123, WP234, WP345, WP456, WP567, WP678 of 3P4W:
[(Voltage range)
×
(Current range)
×
(Integration full
scale)]
×
3
Example: If integrating the power value for 1 hour with the
300 V range and the 10 A range for WP123, the integrated
active power full scale is determined to be 9 kWh.
±
5 V DC for a value of
±
9 kWh
*1: If the voltage for the integrated value would exceed
±
5 V, analog output will switch to 0 V before continuing to vary
again.
*2: Value always has a negative sign.
