193
Specications of Input, Output, and Measurement
Display specications
Display language Japanese, English, Chinese (simplied)
The Chinese-language user interface will be available with rmware version 1.20.
Display 10.1″ WXGA TFT color LCD (1280
×
800 dots)
Dot pitch 0.1695 (V) mm
×
0.1695 (H) mm
Display value
resolution
999999 count (including integrated values)
Display update
interval
Measured values: Approx. 200 ms (independent of internal data refresh interval)
Waveforms: Based on waveform recording settings
Screen Measurement screen, Input Settings screen, System Settings screen, File Operation
screen
Warning display When input-channel a voltage or a current peak-over condition is detected, when no
synchronization source is detected.
Warning marks for all channels will be displayed on any page of the screen.
Specications of operating part
Control device Power button
×
1, rubber keys
×
23, rotary knobs
×
2, touchscreen
Touchscreen Projected capacitive type
Rotary knob 30 notches, 15 pulses, lamp-equipped
Key Mechanical switch type, lamp-equipped
×
12, no-lamp-equipped
×
11
• Lamp-equipped
Green: MEAS, INPUT, SYSTEM, FILE, AUTO
×
2, SINGLE
Red: HOLD, PEAK HOLD, REMOTE/LOCAL
Red/green: START/STOP, RUN/STOP
• No-lamp-equipped
Pages (right and left), SAVE, COPY, up for U, down for U, up for I, down for I
0 ADJ, DATA RESET, MANUAL
Key lock Holding down the REMOTE / LOCAL key for 3 s can turn the key lock on/o󰀨.
While the key lock is engaged, the key lock icon is displayed on the screen.
System reset The instrument setting is reset to the initial state.
However, the language and communications settings are not reset.
Boot-key reset The instrument’s settings are reverted to their factory defaults if the instrument is turned on
while the SYSTEM key is held down.
All settings, including the language and communications settings, are reverted to their
factory defaults.
File operation Displaying data list stored on a USB ash drive, formatting a USB ash drive, creating new
folders, renaming folders/les, copying/deleting les, updating the rmware, displaying
screenshots, creating/loading setting les
Specications
HIOKI PW8001A961-00
