Measured Value Save Data Format
Output items
Instrument
symbol
Header and order
Current RMS value Irms
Irms1, Irms2, Irms3, Irms4, Irms5, Irms6, Irms7, Irms8
Irms12, Irms23, Irms34, Irms45, Irms56, Irms67, Irms78
Irms123, Irms234, Irms345, Irms456, Irms567, Irms678
RMS equivalent of average
rectied voltage value
Imn
Imn1, Imn2, Imn3, Imn4, Imn5, Imn6, Imn7, Imn8
Imn12, Imn23, Imn34, Imn45, Imn56, Imn67, Imn78
Imn123, Imn234, Imn345, Imn456, Imn567, Imn678
Current AC component Iac Iac1, Iac2, Iac3, Iac4, Iac5, Iac6, Iac7, Iac8
Current simple average Idc Idc1, Idc2, Idc3, Idc4, Idc5, Idc6, Idc7, Idc8
Current fundamental wave
component
Ifnd Ifnd1, Ifnd2, Ifnd3, Ifnd4, Ifnd5, Ifnd6, Ifnd7, Ifnd8
Current waveform peak (+) Ipk+ PIpk1, PIpk2, PIpk3, PIpk4, PIpk5, PIpk6, PIpk7, PIpk8
Current waveform peak (−) Ipk− MIpk1, MIpk2, MIpk3, MIpk4, MIpk5, MIpk6, MIpk7, MIpk8
Total harmonic current
distortion
Ithd Ithd1, Ithd2, Ithd3, Ithd4, Ithd5, Ithd6, Ithd7, Ithd8
Current ripple factor Irf Irf1, Irf2, Irf3, Irf4, Irf5, Irf6, Irf7, Irf8
Current unbalance rate Iunb Iunb123, Iunb234, Iunb345, Iunb456, Iunb567, Iunb678
Active power P
P1, P2, P3, P4, P5, P6, P7, P8
P12, P23, P34, P45, P56, P67, P78
P123, P234, P345, P456, P567, P678
Fundamental wave active
power
Pfnd
Pfnd1, Pfnd2, Pfnd3, Pfnd4, Pfnd5, Pfnd6, Pfnd7, Pfnd8
Pfnd12, Pfnd23, Pfnd34, Pfnd45, Pfnd56, Pfnd67, Pfnd78
Pfnd123, Pfnd234, Pfnd345, Pfnd456, Pfnd567, Pfnd678
Apparent power S
S1, S2, S3, S4, S5, S6, S7, S8
S12, S23, S34, S45, S56, S67, S78
S123, S234, S345, S456, S567, S678
Fundamental wave
apparent power
Sfnd
Sfnd1, Sfnd2, Sfnd3, Sfnd4, Sfnd5, Sfnd6, Sfnd7, Sfnd8
Sfnd12, Sfnd23, Sfnd34, Sfnd45, Sfnd56, Sfnd67, Sfnd78
Sfnd123, Sfnd234, Sfnd345, Sfnd456, Sfnd567, Sfnd678
Reactive power Q
Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8
Q12, Q23, Q34, Q45, Q56, Q67, Q78
Q123, Q234, Q345, Q456, Q567, Q678
Fundamental wave reactive
power
Qfnd
Qfnd1, Qfnd2, Qfnd3, Qfnd4, Qfnd5, Qfnd6, Qfnd7, Qfnd8
Qfnd12, Qfnd23, Qfnd34, Qfnd45, Qfnd56, Qfnd67, Qfnd78
Qfnd123, Qfnd234, Qfnd345, Qfnd456, Qfnd567, Qfnd678
Power factor
λ
PF1, PF2, PF3, PF4, PF5, PF6, PF7, PF8
PF12, PF23, PF34, PF45, PF56, PF67, PF78
PF123, PF234, PF345, PF456, PF567, PF678
Fundamental wave power
factor
λ
fnd
PFfnd1, PFfnd2, PFfnd3, PFfnd4, PFfnd5, PFfnd6, PFfnd7, PFfnd8
PFfnd12, PFfnd23, PFfnd34, PFfnd45, PFfnd56, PFfnd67, PFfnd78
PFfnd123, PFfnd234, PFfnd345, PFfnd456, PFfnd567, PFfnd678
Voltage phase angle
θ
U Udeg1, Udeg2, Udeg3, Udeg4, Udeg5, Udeg6, Udeg7, Udeg8
Current phase angle
θ
I Ideg1, Ideg2, Ideg3, Ideg4, Ideg5, Ideg6, Ideg7, Ideg8
Power phase angle
φ
DEG1, DEG2, DEG3, DEG4, DEG5, DEG6, DEG7, DEG8
DEG12, DEG23, DEG34, DEG45, DEG56, DEG67, DEG78
DEG123, DEG234, DEG345, DEG456, DEG567, DEG678
Voltage frequency fU FU1, FU2, FU3, FU4, FU5, FU6, FU7, FU8
Current frequency fI FI1, FI2, FI3, FI4, FI5, FI6, FI7, FI8
Integrated positive current
value
Ih+ PIH1, PIH2, PIH3, PIH4, PIH5, PIH6, PIH7, PIH8
Integrated negative current
value
Ih− MIH1, MIH2, MIH3, MIH4, MIH5, MIH6, MIH7, MIH8
