Symbols and Abbreviations
Others
Indicates useful advice concerning instrument performance and operation.
*
Indicates additional information is provided below.
(p. ) Indicates the page number to refer to.
START
(Bold letters)
Indicates the names of the control keys.
[ ]
Indicates the names of user interface elements on the screen.
Windows Unless otherwise noted, the term Windows is used generically to refer to Windows 10.
Current sensor Sensors for measuring currents are collectively referred to as current sensors.
S/s
For this product, the number of times the analog input signal is digitized is indicated in
samples per second (S/s).
Example: 20 MS/s (20 megasamples per second) signies 20
×
10
6
samples per
second.
Accuracy labeling
The instrument accuracy is expressed by dening a percentage of the reading, a percentage of the
range, a percentage of the full scale, a percentage of the setting, or a limit value for errors in terms
of digits.
% of reading
Reading (display value)
Indicates the value displayed by the instrument.
Limit values for reading errors are expressed as a percentage of the reading (“% rdg”).
% of range
Range
Indicates the measurement range of the instrument.
Limit values for range errors are expressed as a percentage of the range (“% rng”).
f.s.
Full scale (rated current)
For this instrument, this mainly indicates the rated current of the current sensor.
Limit values for full-scale errors are expressed as a percentage of the full scale (“% f.s.”).
digits
Digit (resolution)
Indicates the minimum display unit (in other words, the smallest digit that can have a
value of 1) for a digital measuring instrument.
Limit values for digit errors are expressed using digits.
