Connecting and Setting the LAN Interface
Example network environment architectures
Example 1: Connecting the instrument to an existing network
When connecting the instrument to an existing network, you must rst have the network system
administrator (department) allocate the following settings. Ensure that the instrument uses a unique
address not being used by any other device on the network.
IP address ______ . ______ . ______ . ______
Subnet mask ______ . ______ . ______ . ______
Default gateway ______ . ______ . ______ . ______
When connecting a measuring instrument to an existing network (provide one of the
following)
• 1000Base-T-compatible straight cable (commercially available cable, up to 100 m in length)
(For 100Base or 10Base networking, you can also use a 100Base-TX or a 10Base-T cable.)
• 9642 LAN Cable with cross-conversion connector (optional)
Example 2: Adding a LAN port to a computer connected to an existing network and
connecting the instrument to the new port
Congure the IP address, subnet mask, and default gateway of the new LAN port after verifying the
proper settings with your network system administrator.
Example 3: Connecting one computer and multiple instruments using a hub
When creating a local network not connected externally, it is recommended to use private IP
addresses such as those shown in the example.
When creating a network with a network address of 192.168.1.0/24
IP address
Computer: 192.168.1.1
Instrument: 192.168.1.2, 192.168.1.3, 192.168.1.4, etc. (progressing in order)
Subnet mask 255.255.255.0
Default gateway 0.0.0.0
Example 4: Connecting a computer and the instrument one-to-one with the 9642 LAN Cable
When connecting a computer and the instrument one-to-one with the conversion connector included
with the 9642 LAN Cable, you may set the IP address as desired. However, it is recommended to
use a private IP address.
IP address
Computer: 192.168.1.1
Instrument: 192.168.1.2 (Use a di󰀨erent value.)
Subnet mask 255.255.255.0
Default gateway 0.0.0.0
When connecting the measuring instrument and a computer one-to-one, you will need one
of the following:
• 1000Base-T-compatible cross cable (up to 100 m)
• 1000Base-T-compatible straight cable and cross-conversion connector (up to 100 m)
• 9642 LAN Cable with cross-conversion connector (optional)
Connecting with computers
