Specications of Input, Output, and Measurement
(4) Pulse input specications (Ch. A, Ch. B, Ch. C, Ch. D, Ch. E, Ch. F, Ch. G, Ch. H)
Detection level Low: approx. 0.8 V or less; high: approx. 2.0 V or more
Measurement
frequency band
0.1 Hz to 2 MHz (when the duty ratio is set at 50%)
Minimum detection
width
0.25 µs or more
Pulse noise lter
(PNF)
O󰀨, weak, strong (positive/negative pulses of less than 0.25 µs is ignored with the weak
setting; less than 5 µs with the strong setting)
Measurement range 2 MHz
Measurement
accuracy
0.01% of reading
Display range 0.1 Hz to 2.00000 MHz
Unit Hertz (Hz), revolutions per minute (r/min)
Frequency division
setting range
±
1 to 60000
Rotation direction
detection
Settable in [A-D] and [E-H] each
Pattern 2 to Pattern 5 of motor analysis mode
Detects direction based on lead/lag of Ch. B and Ch. C in [A-D].
Detects direction based on lead/lag of Ch. F and Ch. G in [E-H].
Mechanical angle
origin detection
Settable in [A-D] and [E-H] each
Pattern 2 to Pattern 5 of motor analysis mode
Ch. B frequency division is cleared at Ch. D rising or falling edge in [A-D].
Ch. F frequency division is cleared at Ch. H rising or falling edge in [E-H].
Specications
