44
Setting Wiring Mode and Conguring Current Sensor Settings
Representative values of current sensor phase characteristics
See the table below for information about the current sensor phase characteristics.
Model name Frequency (kHz)
Representative value of
phase di󰀨erence between
input and output (
°
)
CT6841 100.0 −1.82
CT6843 100.0 −1.68
CT6844 50.0 −1.29
CT6845 20.0 −0.62
CT6846 20.0 −1.89
CT6862 300.0 −10.96
CT6863 100.0 −4.60
CT6865 1.0 −1.21
CT6875 200.0 −10.45
CT6875-01 200.0 −12.87
CT6876 200.0 −12.96
CT6876-01 200.0 −14.34
CT6877 100.0 −2.63
CT6877-01 100.0 −3.34
CT6904 300.0 −9.82
9709 20.0 −1.11
PW9100 300.0 −2.80
For all current sensors, the values are representative ones under the following conditions.
Standard cable length (not using the extension cable)
With the conductor positioned at the center of the sensor
For the phase characteristics information when using CT9557, contact your authorized Hioki
distributor or reseller.
HIOKI PW8001A961-00
