8-21
Special Features
Wireless Distribution System (WDS) and Spanning Tree Protocol (STP)
Figure 8-7. Configuring WDS Link Parameters with WEP Security
To Configure WDS Link Parameters with WEP Security:
1. Select Special Features > WDS.
2. To enable a WDS link, choose Enabled for the specific link option.
3. To set the radio to establish the WDS link, use the Radio drop-down.
4. Enter the remote MAC Address or, if AP detection is enabled, select the
remote MAC Address from the drop-down of the access point to which
you are trying to establish the WDS link.
The Security mode is preconfigured when the WLAN Security is config-
ured. See Table 7-4, “WLAN 1 and WDS Security Configuration,” on page 7-17.
5. Modify defaulted SSID, if necessary.
6. Enter the WEP Key, adhering to previous set key parameters.
7. Select [Update] to save the settings.
