187
dynamic: Specifies dynamically configured MAC-to-VLAN entries.
mac-address mac-address: Specifies the MAC address in the MAC-to-VLAN entry. The format
of the
mac-address argument is H-H-H.
mask mac-mask: Specifies the mask for matching MAC addresses in MAC-to-VLAN entries. For
the
mac-mask argument, the high-order bits must be consecutive 1s in binary notation or
consecutive Fs in hexadecimal notation. The default value is ffff-ffff-ffff.
static: Specifies statically configured MAC-to-VLAN entries.
vlan vlan-id: Specifies the VLAN in MAC-to-VLAN entries. The value range for the vlan-id
argument is 1 to 4094.
Examples
# Display all MAC-to-VLAN entries.
<Sysname> display mac-vlan all
The following MAC VLAN entries exist:
State: S - Static, D - Dynamic
MAC address Mask VLAN ID Dot1q State
0008-0001-0000 ffff-ff00-0000 5 3 S
0002-0001-0000 ffff-ffff-ffff 5 3 S&D
Total MAC VLAN entries count: 2
Table 39 Command output
Field Description
S - Static Statically configured MAC-to-VLAN entries.
D - Dynamic Dynamically configured MAC-to-VLAN entries.
MAC address MAC address of the MAC-to-VLAN entry.
Mask MAC address mask of the MAC-to-VLAN entry.
VLAN ID VLAN ID of the MAC-to-VLAN entry.
Dot1q 802.1p priority of the VLAN in the MAC-to-VLAN entry.
State
State of a MAC-to-VLAN entry:
• S—The MAC-to-VLAN entry is configured statically.
• D—The MAC-to-VLAN entry is dynamically issued by the authentication
server.
• S&D—The MAC-to-VLAN entry is configured both statically and
dynamically.
Related commands
mac-vlan mac-address
display mac-vlan interface
Use display mac-vlan interface to display all ports that are enabled with the MAC-based
VLAN feature.
Syntax
display mac-vlan interface
