198
Field Description
Protocol type
Protocol type or encapsulation format specified by the protocol
template.
Related commands
display protocol-vlan interface
port hybrid protocol-vlan
protocol-vlan
port hybrid protocol-vlan
Use port hybrid protocol-vlan to associate a port with the specified protocol-based VLAN.
Use undo port hybrid protocol-vlan to disassociate a port from the specified
protocol-based VLAN.
Syntax
port hybrid protocol-vlan vlan vlan-id { protocol-index [ to protocol-end ]
| all }
undo hybrid protocol-vlan
{ vlan vlan-id { protocol-index [ to protocol-end ]
| all } | all }
Default
A port is not associated with a protocol-based VLAN.
Views
Layer 2 Ethernet interface view
Layer 2 aggregate interface view
Predefined user roles
network-admin
Parameters
vlan vlan-id: Specifies a VLAN by its ID in the range of 1 to 4094.
protocol-index
: Specifies a beginning protocol template index in the range of 0 to 65535.
to protocol-end: Specifies an end protocol template index of a protocol template range, in the
range of 0 to 65535. The value for this argument must be greater than or equal to the beginning
protocol template index.
all
: Specifies all protocol templates.
Usage guidelines
For this command to take effect, perform the following tasks:
1. Create a VLAN and associate it with the specified protocol templates.
2. Set the port link type to hybrid.
3. Configure the port to allow the protocol-based VLAN to pass through.
When you execute the
undo port hybrid protocol-vlan command on a port, follow these
guidelines:
• If you specify both the
vlan-id argument and the all keyword, this command disassociates
the port from all protocol templates of the specified VLAN.
