VLAN mapping commands
display vlan mapping
Use display vlan mapping to display VLAN mapping information.
Syntax
display vlan mapping [ interface interface-type interface-number ]
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
interface interface-type interface-number: Specifies an interface by its type and
number. If you do not specify an interface, the command displays VLAN mapping information on all
interfaces.
Examples
# Display VLAN mapping information on all interfaces.
<Sysname> display vlan mapping
Interface GigabitEthernet1/0/1:
Outer VLAN Inner VLAN Translated Outer VLAN Translated Inner VLAN
10 N/A 120 N/A
Outer VLAN Inner VLAN Nested VLAN
200 100 300
Interface GigabitEthernet1/0/2:
Outer VLAN Inner VLAN Translated Outer VLAN Translated Inner VLAN
4-4094 N/A 100 N/A
Interface GigabitEthernet1/0/3:
Outer VLAN Inner VLAN Translated Outer VLAN Translated Inner VLAN
12 N/A 110 12
Interface GigabitEthernet1/0/4:
Outer VLAN Inner VLAN Translated Outer VLAN Translated Inner VLAN
11 30 130 40
Table 55 Command output
Field Description
Outer VLAN
Original outer VLAN.
This field indicates the original VLAN for one-to-one VLAN mapping,
many-to-one VLAN mapping, and one-to-two VLAN mapping.
