197
Field Description
Status
Whether the protocol-based VLAN has taken effect:
• Active—The protocol-based VLAN has taken effect.
• Inactive—The protocol-based VLAN has not taken effect.
Related commands
display protocol-vlan vlan
port hybrid protocol-vlan
protocol-vlan
display protocol-vlan vlan
Use display protocol-vlan vlan to display information about protocol-based VLANs.
Syntax
display protocol-vlan vlan { vlan-id1 [ to vlan-id2 ] | all }
Views
Any view
Predefined user roles
network-admin
network-operator
Parameters
vlan-id1: Specifies a protocol-based VLAN ID in the range of 1 to 4094.
vlan-id1 to vlan-id2: Specifies a protocol-based VLAN ID range. Both the vlan-id1 and the
vlan-id2 arguments are in the range of 1 to 4094. The value for the vlan-id2 argument must be
equal to or greater than the value for the
vlan-id1 argument.
all: Specifies all protocol-based VLANs.
Examples
# Displays information about all protocol-based VLANs.
<Sysname> display protocol-vlan vlan all
VLAN ID: 2
Protocol index Protocol type
0 IPv4
65535 IPv6
VLAN ID: 3
Protocol index Protocol type
0 IPv4
65535 LLC DSAP 0x11 SSAP 0x22
Table 43 Command output
Field Description
VLAN ID ID of the protocol-based VLAN.
Protocol index Protocol template index.
