HPE FlexNetwork 5130 EI Series User Manual

252
Field Description
Inner VLAN
Original inner VLAN.
This field displays
N/A
for one-to-one VLAN mapping, many-to-one
VLAN mapping, and one-to-two VLAN mapping.
Translated Outer VLAN
Translated outer VLAN.
This field indicates the translated VLAN for one-to-one VLAN mapping
and many-to-one VLAN mapping.
Translated Inner VLAN
Translated inner VLAN.
This field displays
N/A
for one-to-one VLAN mapping and many-to-one
VLAN mapping.
Related commands
vlan mapping
vlan mapping
Use vlan mapping to configure VLAN mapping on an interface.
Use
undo vlan mapping to cancel the VLAN mapping configuration.
Syntax
vlan mapping { vlan-id translated-vlan vlan-id | nest { range
vlan-range-list | single vlan-id-list } nested-vlan vlan-id | nni | tunnel
outer-vlan-id inner-vlan-id translated-vlan outer-vlan-id inner-vlan-id
| uni { range vlan-range-list | single vlan-id-list } translated-vlan
vlan-id
}
undo vlan mapping { vlan-id translated-vlan vlan-id | all | nest { range
vlan-range-list | single vlan-id-list } nested-vlan vlan-id | nni | tunnel
outer-vlan-id inner-vlan-id translated-vlan outer-vlan-id inner-vlan-id
|
uni { range vlan-range-list | single vlan-id-list } translated-vlan
vlan-id }
Default
No VLAN mapping is configured on an interface.
Views
Layer 2 Ethernet interface view
Layer 2 aggregate interface view
Predefined user roles
network-admin
Parameters
vlan-id translated-vlan vlan-id: Specifies the original VLAN and translated VLAN for a
one-to-one VLAN mapping. The value range for the
vlan-id argument is 1 to 4094. The original
VLAN and the translated VLAN cannot be the same.
uni range vlan-range-list translated-vlan vlan-id: Specifies the original VLAN
ranges and the translated VLAN for a many-to-one VLAN mapping on the customer-side port. The
vlan-range-list argument specifies a space-separated list of up to 10 VLAN items. Each item
specifies a VLAN ID or a range of VLAN IDs in the form of
vlan-id1 to vlan-id2. The value
range for VLAN IDs is 1 to 4094. The value for the
vlan-id2 argument must be greater than the
value for the
vlan-id1 argument. The value range for the vlan-id argument is 1 to 4094.
