HPE FlexNetwork 5130 EI Series User Manual

209
Name: VLAN 0003
Tagged ports: None
Untagged ports:
GigabitEthernet1/0/2
GigabitEthernet1/0/3
VLAN ID: 4
VLAN type: Static
Private VLAN type: Secondary
Route interface: Not configured
Description: VLAN 0004
Name: VLAN 0004
Tagged ports: None
Untagged ports:
GigabitEthernet1/0/2
GigabitEthernet1/0/4
Table 46 Command output
Field Description
VLAN type VLAN type, dynamic or static.
Private VLAN type
Private VLAN type:
• Primary—Primary VLAN.
• Secondary—Secondary VLAN.
• Isolated secondary—Secondary VLAN configured with port
isolation at Layer 2.
Route interface
Whether a VLAN interface is created for the VLAN:
• Configured.
• Not configured.
IPv4 address
Primary IPv4 address of the VLAN interface. This field is displayed only
when an IPv4 address is configured for the VLAN interface.
When the VLAN interface is also configured with secondary IPv4
addresses, you can view them by using one of the following commands:
•
display interface vlan-interface.
•
display this (VLAN interface view).
IPv4 subnet mask
Subnet mask for the primary IPv4 address of the VLAN interface. This
field is displayed only when an IPv4 address is configured for the VLAN
interface.
