259
Field Description
Management address OID Management address object ID.
Port VLAN ID(PVID) Port VLAN ID.
Port and protocol VLAN
ID(PPVID)
Port protocol VLAN ID.
Port and protocol VLAN
supported
Indicates whether protocol VLAN is supported on the port.
Port and protocol VLAN enabled Indicates whether protocol VLAN is enabled on the port.
Link aggregation supported Indicates whether link aggregation is supported on the port.
Link aggregation enabled Indicates whether link aggregation is enabled on the port.
Aggregation port ID Member port ID, which is 0 when link aggregation is disabled.
Auto-negotiation supported Indicates whether autonegotiation is supported on the port.
Auto-negotiation enabled Indicates whether autonegotiation is enabled on the port.
OperMau Speed and duplex state of the port.
Power port class
PoE port class:
• PSE—Power sourcing equipment.
• PD—Powered device.
PSE power supported Indicates whether the device can operate as a PSE.
PSE power enabled Indicates whether the device is operating as a PSE.
PSE pairs control ability Indicates whether the pair selection ability is available.
Power pairs
Power supply mode:
• Signal—Uses data pairs to supply power.
• Spare—Uses spare pairs to supply power.
Port power classification
Power class of the PD:
• Class 0.
• Class 1.
• Class 2.
• Class 3.
• Class 4.
Power type
Power supply type:
• Type 1 PD.
• Type 2 PD.
• Type 1 PSE.
• Type 2 PSE.
Power source
Power source:
• When the power supply type is PSE, options are:
{ Unknown—Unknown power supply.
{ Primary—Primary power supply.
{ Backup—Backup power supply.
{ Reserved.
• When the power supply type is PD, options are:
{ Unknown—Unknown power supply.
{ PSE—PSE power supply.
{ Local—Local power supply.
{ PSE and local—PSE and local power supplies.
