4.4 Scenarios for Connecting the ECC800-Pro in the
Smart Module
4.4.1 Connecting a Monitoring Cable to the ECC800-Pro
Collector
Procedure
Step 1 For details about how to connect monitoring cables to the ECC800-Pro, see the
Smart Modular Data Center Management System Wiring Diagram.
The onsite wiring diagram of the management system prevails. The method described in
this section is for reference only.
----End
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 4 Connecting Monitoring Cables to Devices
