4.2.5.3 Connecting a Monitoring Cable to the UPS5000-E/UPS5000-H/
UPS5000-S
Prerequisites
A network cable used for monitoring is prepared.
Procedure
Step 1 Connect one end of a network cable to the FE port on the UPS5000-E/UPS5000-H/
UPS5000-S monitoring card.
Step 2 Connect the other end of the network cable to the Ethernet port on the LAN
switch.
----End
4.2.6 Connecting the SmartLi Monitoring Cable
Prerequisites
A network cable used for monitoring is prepared.
Procedure
Step 1 Connect one end of the network cable to the FE port on the monitoring interface
unit.
Figure 4-15 Monitoring interface unit of the SmartLi
(1) Monitoring interface unit
