Step 16 In the Modify dialog box, set Connection Mode.
Table 6-33 Connection modes
Connection Mode Description
Compatible ● On the ECC800-Pro WebUI, set Enable Security
Authentication to Disable.
● In transparent transmission channel management
settings, the compatibility mode has security
risks. You are advised to select the security
protocol mode.
Security protocol Enter the authentication password set on the
ECC800-Pro WebUI.
Step 17 After the setting is complete, click OK.
----End
6.5.2 Adding Sensors
6.5.2.1 Adding Dry Contact Interface Devices
6.5.2.1.1 Setting Door Status Sensor Monitoring Parameters on the ECC800-Pro
Web
After connecting a door status sensor (DSS) to the AI/DI port of an ECC800-Pro
collector, you need to set DSS parameters on the web user interface (WebUI) of
the collector.
Prerequisites
● You have obtained the IP address, and login user name and password for the
ECC800-Pro collector.
● A PC with an IP address in the same network segment as the ECC800-Pro
collector is prepared, and the PC has been connected to the ECC800-Pro
collector over a switch.
Context
This section describes how to set DSS monitoring parameters when a DSS is
connected to the AI/DI_1 port of the ECC800-Pro collector. Set the parameters
based on the actual port connected to the DSS onsite.
Procedure
Step 1 Log in to the WebUI of the ECC800-Pro collector.
Step 2 Choose Monitoring > System > ECC800 > Running Parameters > AI/DI_1 Port
Settings.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 6 Adding Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 241
