Step 7 Set the address of the access controller using the DIP switch, as shown in Table
7-19.
Table 7-19 Setting the address of the access controller
Address Value Toggle Switch 1 Toggle Switch 2
0 OFF OFF
1 ON OFF
2 OFF ON
3 ON ON
Step 8 Set the baud rate of the access controller to 19200. The preset data bit, stop bit,
and check bit are 8, 1, and none respectively.
----End
7.2.6.2 Replacing a Double-Door Magnetic Lock
Prerequisites
● A double-door magnetic lock needs to be replaced.
● Spare magnetic locks of the same model are available and functional.
Context
Prepare magnetic locks of the same model.
Recommended tools and materials: crimping tool, Phillips screwdriver, hex key
(delivered with the product package), step ladder (2 m).
Procedure
Step 1 Remove the cover of the magnetic lock, as shown in Figure 7-27.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 7 Device Maintenance
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 307
