6.4.1.3 iBOX and iBAT Networking
Prerequisites
Before networking, ensure that all the iBOXs and iBATs have no network
parameters, that is, the RF_Z indicator on the iBOX is steady green and the
RUN/ALM indicator on the iBAT is steady red.
● If the RF_Z indicator on the iBOX is not steady green, hold down the
networking switch on the iBOX for 10–20 seconds to clear the original network.
● If the RUN/ALM indicator on the iBAT is not steady red, hold down the
networking switch on the iBAT for at least 5 seconds to clear the original
network.
● Do not operate the networking switch during networking. Otherwise, the
networking fails.
Context
To prevent the iBAT in a
dierent group from connecting to another iBOX, ensure
that only one iBOX is under networking at a time. That is, only the RF_Z indicator
of this iBOX is blinking at super short intervals.
Procedure
Step 1 Hold down the networking switch on the iBOX for 2 seconds. The ALM indicator
blinks red once, and the RF_Z indicator turns from steady green to blinking green
at super short intervals, which indicates that the iBOX is being networked.
● Blinking at long intervals: The indicator is on for 1s and then o for 1s alternately.
● Blinking at super short intervals: The indicator is on for 0.05s and then o for 0.05s
alternately.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 6 Adding Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 166
