Step 7 Select the new ngerprint and card reader, and click Connection test. When
Connection success is displayed, the replacement is complete.
----End
7.2.6.6 Replacing a Card Reader with a Keypad
Prerequisites
● Recommended tool: Phillips screwdriver
● A card reader with a keypad needs to be replaced.
● A spare card reader with a keypad of the same model is available and
functional.
Context
Figure 7-40 Card reader with a keypad
Procedure
Step 1 Remove the screw that secures the card reader with a keypad, and remove the
cable, as shown by (1), (2), and (3) in Figure 7-41.
Figure 7-41 Removing a bottom plate
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 7 Device Maintenance
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 316
