6.5.3.5 Creating a NEWABEL CHD200G Fingerprint Controller on the NetEco
This section applies to the settings of the card reader with a keypad, ngerprint
and card reader, and ngerprint and card reader with a keypad.
Prerequisites
● You have the operation rights for Planning Conguration.
● You have created a management domain for the device to be added on the
Planning Conguration page.
● The access controller has been connected to the NetEco.
● The Newabel CHD200G
ngerprint controller and the access controller are
connected to the same ECC800-Pro collector.
● The ECC800-Pro connected to the device has been connected to the NetEco.
● Transparent transmission has been enabled for the COM port on the ECC800-
Pro or UIM20A expansion module to which the device is connected.
Procedure
Step 1 Log in to the NetEco client.
Step 2 On the main menu, choose Device Management >
Conguration > Planning
Conguration.
Step 3 Choose the management domain where you want to create a device from the
navigation tree on the left.
Step 4 In the lower-left corner of the page, click the Device tab.
Step 5 In the Device area, select Fingerprint Controller from the drop-down list box.
Step 6 Select the device to be added and drag its icon to the management domain.
To delete a device, click the device and choose Delete under .
Step 7 Specify parameters in the right pane based on the following table.
Table 6-42 Device parameter description
Parameter
Description
Managed Object
Name
Device name
IP Set this parameter to the IP address of the collector to
which the device is connected.
Port Set this parameter to the port through which the device
connects to the collector.
For details about the ports on the ECC800-Pro collector, see
6.5.1.4 Setting RS485 Parameters for the ECC800-Pro
Collector.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 6 Adding Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 262
