Table 4-1 Description of ports on the TaiShan 200 server (Model 2280)
No. Port Type Description
1 eth0 GE port Used for connecting to the LAN switch.
● Scenario where the southbound and
northbound networks are not isolated:
Connect eth0 and eth1, which are congured
as bond0 by default, to provide southbound
and northbound services. Connect eth2 and
eth3, which are
congured as bond1 by
default, to provide southbound 2 services.
● Scenario where the southbound and
northbound networks are isolated: Connect
eth0 and eth1, which are
congured as
bond0 by default, to provide northbound
services. Connect eth2 and eth3, which are
congured as bond1 by default, to provide
southbound services. Connect eth4 and eth5,
which are congured as bond2 by default, to
provide southbound 2 services.
2 eth1 GE port
3 eth2 GE port
4 eth3 GE port
5 eth4 GE port
6 eth5 GE port
7 eth6 GE port Reserved.
8 eth7 GE port
9 iBMC remote
management
port
Used for connecting to a PC to manage the
TaiShan 200 server (Model 2280).
10 Server serial
port
Used for connecting to an SMS modem or for
commissioning.
11 VGA port Used for connecting to a monitor.
12 USB port Used for connecting to an external device.
4.1.1.2 Server Ports (2288X V5 Server)
The 2288X V5 server is a next-generation Huawei data center server that
integrates patented technologies such as Dynamic Energy Management
Technology (DEMT) and fault diagnosis & management (FDM). It features
ecient computing, high security and reliability, and an open ecosystem. Suitable
for
ecient acceleration of applications such as big data, distributed storage,
native applications, high-performance computing, and databases, the server aims
to meet the requirements of
diversied computing and green computing in data
centers.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 4 Connecting Monitoring Cables to Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 68
