Figure 4-10 Main control module
(1) COM/FE port
Step 2 Connect the other end of the network cable to the Ethernet port on the LAN
switch.
----End
4.2.5 Connecting the UPS Monitoring Cable
4.2.5.1 Connecting the UPS2000-G/UPS2000-H Monitoring Cable (SNMP)
Prerequisites
A network cable used for monitoring is prepared.
Procedure
Step 1 Connect one end of a network cable to the Ethernet port on the SNMP card of the
UPS2000-G/UPS2000-H.
Figure 4-11 Ethernet port
(1) Ethernet port
Step 2
Connect the other end of the network cable to the Ethernet port on the LAN
switch.
----End
