Huawei iMaster NetEco V600R021C10 User Manual

Parameter Description
Serial port address Indicates the device address planned
for the PDU8000. The devices with the
same address cannot connect to the
same port. When creating a PDU8000
on the NetEco, set Device Address to
the same value.
Step 4 Set RS485 port parameters for the collector based on the value of BaudRate,
DataBit, StopBit, and Parity of the device. For ECC800-Pro collector settings, see
6.5.1.4 Setting RS485 Parameters for the ECC800-Pro Collector.
----End
6.5.7.2 Creating a PDU on the NetEco
This section describes how to create a PDU on the NetEco.
Prerequisites
● You have created a management domain for the device to be added on the
Planning
Conguration page.
● The ECC800-Pro connected to the device has been connected to the NetEco.
● Transparent transmission has been enabled for the COM port on the ECC800-
Pro or UIM20A expansion module to which the device is connected.
Procedure
Step 1 Log in to the NetEco client.
Step 2 On the main menu, choose Device Management >
Conguration > Planning
Conguration.
Step 3 Choose the management domain where you want to create a device from the
navigation tree on the left.
Step 4 In the lower-left corner of the page, click the Device tab.
Step 5 In the Device area, select PDU from the drop-down list box.
Step 6 Select the device to be added and drag its icon to the management domain.
NO TE
To delete a device, click the device and choose Delete under .
Step 7 Click the device. In the device parameter area on the right, set device parameters
according to the following table.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 6 Adding Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 270
