No. Description
2 Four 10GE SFP+ Ethernet optical ports
Modules and cables supported:
● GE optical module
● GE-CWDM optical module
● GE-DWDM optical module
● GE optical/electrical module (supporting 100M/1000M auto-
negotiation)
● 10GE SFP+ optical module (OSXD22N00 not supported)
● 10GE-CWDM optical module
● 10GE-DWDM optical module
● 1 m and 3 m SFP+ high-speed cables
● 3 m and 10 m SFP+ AOC cables
● 0.5 m and 1.5 m SFP+ dedicated stack cables (used for
zero-
conguration
stacking)
3 One console port
4 One ETH management port
5 One USB port
6 One PNP button
NOTICE
● Holding down the button for more than 6s restores the factory settings and
resets the device.
● Pressing the button resets the device.
● Resetting the device will interrupt services. Exercise caution when using this
button.
7 Ground screw
NOTE
The screw needs to be used with a ground cable.
8 Power module slot 1
NOTE
Supported power module: 1000 W AC PoE power module (PAC1000S56-CB)
9 Power module slot 2
NOTE
Supported power module: 1000 W AC PoE power module (PAC1000S56-CB)
Item
lists technical specications of the S5335-S24P4X.
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 4 Connecting Monitoring Cables to Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 74
