Networking Requirements
As shown in Figure 1-9, when the configuration change or fault occurs on the switch, the
switch automatically sends an alarm message to the specified NMS. The alarm message sent by
Huawei devices to the Huawei NMS contains the sending time and ID of the alarm message in
addition to the information defined in the protocol.
Figure 1-9 Networking diagram of configuring alarm messages to be sent to the Huawei NMS
NMS
Switch
LoopBack0
1.1.1.1/32
11.1.1.1/24
GE0/0/1
11.1.1.2/24
IP network
Configuration Roadmap
The configuration roadmap is as follows:
1. Assign IP addresses to interfaces.
2. Configure the SNMP version.
3. Configure alarm messages to be sent to the Huawei NMS.
Data Preparation
To complete the configuration, you need the following data:
l IP address of Interface.
l SNMP version
l Source interface for sending alarm messages
l IP address of the NMS
Procedure
Step 1 Assign an IP addresses to the interfaces. The configuration details are not mentioned here.
Step 2 Configure the SNMP version.
# Configure the SNMP version to v2c.
<Quidway> system-view
[Quidway] snmp-agent sys-info version v2c
Step 3 Configure alarm messages to be sent to the NMS.
# Enable the SNMP agent to send alarm messages.
1 SNMP Configuration
Quidway S9300 Terabit Routing Switch
Configuration Guide - Network Management
1-90 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 03 (2010-09-20)
