Huawei Quidway S9300

Pre-configuration Tasks
Before configuring the Trap function, complete the following tasks:
l Assigning an IP address to the switch
l Configuring the routing protocol to make the switch and the NMS accessible
Data Preparation
To configure the Trap function, you need the following data.
No. Data
1 (Optional) Name of the feature that generates alarms
2 (Optional) Name of the alarm that is generated by the feature
3 Destination host address of Trap messages
4 (Optional) Source address of Trap messages
5 (Optional) Queue length of Trap messages
6 (Optional) Saving time of Trap messages
1.17.2 (Optional) Enabling the switch to Send Specified Alarms to
the NM Station
Context
Do as follows on the switch enabled with the SNMP agent:
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
snmp-agent trap enable
The switch is enabled to send alarms.
NOTE
When all trap functions are enabled through the snmp-agent trap enable command or at least three trap
functions are enabled through the snmp-agent trap enable feature-name command:
l you can run the snmp-agent trap disable command to disable all the enabled trap functions.
l you can run any one of the undo snmp-agent trap enable and undo snmp-agent trap disable
commands to restore all trap functions to their default status.
l To disable a specified trap function, you can run the undo snmp-agent trap enable feature-name
command.
----End
Quidway S9300 Terabit Routing Switch
Configuration Guide - Network Management 1 SNMP Configuration
Issue 03 (2010-09-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1-57
