interface gigabitethernet1/0/2
port link-type trunk
port trunk allow-pass vlan 10
ntdp enable
ndp enable
#
cluster
mngvlanid 10
administrator-address 0001-0001-0001 name HUAWEI
#
return
8.5.5 Example for Configuring Devices in the HGMP Cluster to
Access the Outside SNMP Host (in non-NAT Mode)
Networking Requirements
As shown in Figure 8-7, all the Layer 2 switches belong to the same cluster. Administrator-1 is
the administrator switch of the cluster and other switches are member switches. The member ID
of Member-2 is 2 and the member ID of Member-3 is 3.
When Member-1, Member-2, and Member-3 are required to send packets to the SNMP host out
of the cluster, a connection can be set up between the SNMP host and member switches in NAT
or non-NAT mode.
NOTE
In this configuration example where the non-NAT mode is adopted, Member-3 accesses the SNMP host
(3.0.0.1/8).
Quidway S9300 Terabit Routing Switch
Configuration Guide - Network Management 8 HGMP Configuration
Issue 03 (2010-09-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8-73
