Huawei Quidway S9300

ntdp enable
ndp enable
#
cluster
administrator-address 0001-0001-0001 name HUAWEI
#
mngvlanid 10
ip route-static 2.0.0.0 255.0.0.0 10.0.0.1
#
return
l Configuration file of Member-3.
#
sysname Member-3
#
vlan batch 10
#
cluster enable
ntdp enable
ntdp hop 5
ntdp timer 10
ndp enable
#
interface Vlanif10
#
interface gigabitethernet1/0/2
port link-type trunk
port trunk allow-pass vlan 10
ntdp enable
ndp enable
#
cluster
administrator-address 0001-0001-0001 name HUAWEI
#
mngvlanid 10
ip route-static 2.0.0.0 255.0.0.0 10.0.0.1
#
return
8.5.4 Example for Configuring Devices in the HGMP Cluster to
Access the Outside SNMP Host (in NAT Mode)
Networking Requirements
As shown in Figure 8-6, all the Layer 2 switches belong to the same cluster. Administrator-1 is
the administrator switch of the cluster and other switches are member switches. The member ID
of Member-2 is 2 and the member ID of Member-3 is 3.
When Member-1, Member-2, and Member-3 are required to send packets to the SNMP host, a
connection can be set up between the SNMP host out of the cluster and member switches in
NAT or non-NAT mode.
NOTE
In this configuration example where the NAT mode is adopted, Member-3 accesses the outside SNMP host
(3.0.0.1/8).
