ip address 10.1.1.2 255.255.255.0
#
interface GigabitEthernet1/0/0
port hybrid pvid vlan 10
port hybrid untagged vlan 10
#
return
6.37.2 Example for Configuring the FTP Download Test
Networking Requirements
As shown in Figure 6-4:
l Switch B functions as the FTP server.
l A user with the name user1 and the password hello intends to log in to the FTP server to
download the test.txt file.
Figure 6-4 Networking diagram for configuring the FTP download test
SwitchA SwitchB
GE1/0/0
VLANIF10
10.1.1.1/24
GE1/0/0
VLANIF10
10.1.1.2/24
FTP Client
Configuration Roadmap
The configuration roadmap is as follows:
1. Configure Switch A as the NQA client.
2. Create and perform the FTP test on Switch A to check whether a connection between
Switch A and the FTP server can be set up and to check the time for downloading a file
from the FTP server.
Data Preparation
To complete the configuration, you need the following data:
l IP address of the FTP server
l Source IP address for the test
l FTP user name and password
l Operation file of the FTP test
Procedure
Step 1 Configure the IP addresses of Switch A and Switch B. The configuration details are not
mentioned here.
Step 2 Configure Switch B as the FTP server.
<SwitchB> system-view
[SwitchB] ftp server enable
[SwitchB] aaa
Quidway S9300 Terabit Routing Switch
Configuration Guide - Network Management 6 NQA Configuration
Issue 03 (2010-09-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6-143
