8.5.2 Example for Configuring the Interconnection of FTP Servers
and Devices in and out of the HGMP Cluster (in NAT Mode)
Networking Requirements
As shown in Figure 8-4, all the Layer 2 switches belong to the same cluster. Administrator-1 is
the administrator switch of the cluster and other switches are member switches. The member ID
of Member-1 is 1, the member ID of Member-2 is 2 and the member ID of Member-3 is 3.
To upload files to Member-1, Member-2, and Member-3 or download files from them, you can
set up an FTP connection between the devices out of the cluster and member switches in NAT
or non-NAT mode.
NOTE
In this configuration example where the NAT mode is adopted, Member-3 accesses the FTP server
(2.0.0.1/8) out of the cluster and devices out of the cluster access the FTP server (Member-2) in the cluster.
