1 . Test 1 result The test is finished
Send operation times: 3 Receive response times: 3
Completion:success RTD OverThresholds number: 0
Attempts number:1 Drop operation number:0
Disconnect operation number:0 Operation timeout number:0
System busy operation number:0 Connection fail number:0
Operation sequence errors number:0 RTT Stats errors number:0
Destination ip address:3.14.2.14
Min/Max/Average Completion Time: 6/6/6
Sum/Square-Sum Completion Time: 18/108
Last Good Probe Time: 2009-2-27 9:0:42.3
Lost packet ratio: 0 %
6.26 Configuring the PWE3 Ping Test to Check the Multi-
Hop PW
This section describes how to configure a PWE3 ping test to check the connectivity of a multi-
hop PW.
6.26.1 Establishing the Configuration Task
Before configuring a PWE3 ping test for a multi-hop PW, familiarize yourself with the applicable
environment, complete the pre-configuration tasks, and obtain the required data. This can help
you complete the configuration task quickly and accurately.
6.26.2 Configuring Parameters for the PWE3 Ping Test on a Multi-Hop PW
This part describes how to set PWE3 ping test parameters for a multi-hop PW.
6.26.3 Checking the Configuration
After performing the PWE3 ping test for a multi-hop PW, you can view the test result.
6.26.1 Establishing the Configuration Task
Before configuring a PWE3 ping test for a multi-hop PW, familiarize yourself with the applicable
environment, complete the pre-configuration tasks, and obtain the required data. This can help
you complete the configuration task quickly and accurately.
Applicable Environment
To check the connectivity of the multi-hop PW using LDP as the signaling protocol, you can
perform the PWE3 Ping test on the multi-hop PW.
Pre-configuration Tasks
Before configuring the PWE3 Ping test on a multi-hop PW, you must correctly configure the
dynamic multi-hop PW or the static multi-hop PW.
Data Preparation
To configure the PWE3 Ping test on a multi-hop PW, you need the following data.
No.
Data
1 ID of the local end of the PW
2 ID or IP address of the remote end of the PW
